Ultra Double

Ultra 80W LED Integrated 6ft Double Batten with Microwave Sensor & Corridor Dim Function - 4000K

Code
10234
Technical Specification
Volts (V)
220/240
Watts (W)
80
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
10600
Energy Rating
E
80W Ultra LED Integrated Batten - 4000K, Double with Microwave Sensor + Corridor Dim Function 1795mm (6ft)
Download Specification
Full Specification
Downloads
Name
Ultra 80W LED Integrated 6ft Double Batten with Microwave Sensor & Corridor Dim Function - 4000K
Volts (V)
220/240
Watts (W)
80
Colour Temp (K)
4000
Dimmable?
Yes
Lumens (lm)
10600
Life Hours
50000
Beam Angle
134°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
840mA
Energy Consumption (kWh/1000h)
80
IP Rating
IP20
Commodity Code
9405409990
EAN
5013588102344
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01765
Outer Box Qty
4
Height (mm)
82
Width (mm)
109
Length (mm)
1795
Outer Box Height (mm)
250
Outer Box Width (mm)
210
Outer Box Depth (mm)
1820
Candelas (cd)
2850
Equivalent Watts (W)
165
Single Carton Height (mm)
86
Single Carton Width (mm)
114
Single Carton Depth (mm)
1800
Outer Box Volume
0.09555
Individual Product Weight (kg)
2.87
Single Carton Weight (KG)
3.19
Outer Box Weight (kg)
13.86
Plastic Packaging Weight (kg)
0.02
Inner Box Qty
1
Energy Rating
E
Lumens per Watt (lm/W)
133
Electric Class
1
Driver Integral?
Yes
Power Factor
0.97kW
