Ultra Double

80W Ultra LED Integrated Batten - 4000K, Double with Microwave Sensor 1795mm (6ft)

Code
10232
Technical Specification
Volts (V)
220-240
Watts (W)
80
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
10600
80W Ultra LED Integrated Batten - 4000K, Double with Microwave Sensor 1795mm (6ft)
Download Specification
Full Specification
Downloads
Name
80W Ultra LED Integrated Batten - 4000K, Double with Microwave Sensor 1795mm (6ft)
Volts (V)
220-240
Watts (W)
80
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
10600
Life Hours
50,000
Beam Angle
134°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
LED Drive Current
1,080
Energy Consumption (kWh/1000h)
80
IP Rating
IP20
Commodity Code
94054099
EAN
5013588102320
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01765
Outer Box Qty
10
Outer Box CMB
0.1
Height (mm)
82
Width (mm)
109
Length (mm)
1,795
Outer Box Height (mm)
1820
Outer Box Width (mm)
250
Outer Box Depth (mm)
210
Candelas (cd)
2,850
Equivalent Watts (W)
165
Single Carton Height (mm)
1805
Single Carton Width (mm)
120
Single Carton Depth (mm)
90
Individual Product Weight (kg)
2.81
Single Carton Weight (KG)
3.13
Outer Box Weight (kg)
13.63
Plastic Packaging Weight (kg)
0.02
