Ultra Single

Ultra 20W LED Integrated 4ft Single Batten with Microwave Sensor - 4000K

Code
10202
Technical Specification
Volts (V)
220/240
Watts (W)
20
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
2850
Energy Rating
E
20W Ultra LED Integrated Batten - 4000K, Single with Microwave Sensor 1230mm (4ft)
Download Specification
Full Specification
Downloads
Name
Ultra 20W LED Integrated 4ft Single Batten with Microwave Sensor - 4000K
Volts (V)
220/240
Watts (W)
20
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
2850
Life Hours
50000
Beam Angle
156°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
480mA
Energy Consumption (kWh/1000h)
20
IP Rating
IP20
Commodity Code
9405409990
EAN
5013588102023
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.00837
Outer Box Qty
6
Height (mm)
82
Width (mm)
69
Length (mm)
1230
Outer Box Height (mm)
1250
Outer Box Width (mm)
250
Outer Box Depth (mm)
210
Candelas (cd)
650
Equivalent Watts (W)
45
Single Carton Height (mm)
1240
Single Carton Width (mm)
90
Single Carton Depth (mm)
75
Individual Product Weight (kg)
1.41
Single Carton Weight (KG)
1.58
Outer Box Weight (kg)
10.47
Plastic Packaging Weight (kg)
0.005
Outer Box Volume
0.06563
Inner Box Qty
1
Energy Rating
E
Lumens per Watt (lm/W)
143
Electric Class
1
Driver Integral?
Yes
Power Factor
0.96kW
