Ultra Single

50W Ultra LED Integrated Batten - 4000K, Single Emergency with Microwave Sensor + Corridor Dim Function 1795mm (6ft)

Code
10229
Technical Specification
Volts (V)
220-240
Watts (W)
50
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
6350
50W Ultra LED Integrated Batten - 4000K, Single Emergency with Microwave Sensor + Corridor Dim Function 1795mm (6ft)
Download Specification
Full Specification
Name
50W Ultra LED Integrated Batten - 4000K, Single Emergency with Microwave Sensor + Corridor Dim Function 1795mm (6ft)
Volts (V)
220-240
Watts (W)
50
Colour Temp (K)
4000
Dimmable?
No
Lumens (lm)
6350
Life Hours
50,000
Beam Angle
116°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25,000
Frequency (Hz)
50/60
LED Drive Current
1,080
Energy Consumption (kWh/1000h)
50
IP Rating
IP20
Commodity Code
9405409990
EAN
5013588102290
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01218
Outer Box Qty
4
Height (mm)
82
Width (mm)
69
Length (mm)
1,795
Outer Box Height (mm)
1810
Outer Box Width (mm)
170
Outer Box Depth (mm)
205
Candelas (cd)
1,500
Equivalent Watts (W)
100
Single Carton Height (mm)
1805
Single Carton Width (mm)
90
Single Carton Depth (mm)
75
Individual Product Weight (kg)
2.22
Single Carton Weight (KG)
2.62
Outer Box Weight (kg)
11.02
Plastic Packaging Weight (kg)
0.015
Outer Box Volume
0.06308
