Ultra Single

Ultra 50W LED Integrated 6ft Single Batten - 4000K

Code
10224
Technical Specification
Volts (V)
220/240
Watts (W)
50
Colour Temp (K)
4000
Lumens (lm)
7181
50W Ultra LED Integrated Batten - 4000K, Single 1795mm (6ft)
Download Specification
Full Specification
Downloads
Name
Ultra 50W LED Integrated 6ft Single Batten - 4000K
Volts (V)
220/240
Watts (W)
50
Colour Temp (K)
4000
Lumens (lm)
7181
Life Hours
50000
Beam Angle
116°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
1320mA
Energy Consumption (kWh/1000h)
50
IP Rating
IP20
Commodity Code
9405423990
EAN
5013588102245
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01146
Outer Box Qty
4
Height (mm)
82
Width (mm)
69
Length (mm)
1795
Outer Box Height (mm)
180
Outer Box Width (mm)
200
Outer Box Depth (mm)
1820
Candelas (cd)
1500
Equivalent Watts (W)
100
Single Carton Height (mm)
86
Single Carton Width (mm)
74
Single Carton Depth (mm)
1800
Outer Box Volume
0.06552
Individual Product Weight (kg)
1.94
Single Carton Weight (KG)
2.34
Outer Box Weight (kg)
9.75
Plastic Packaging Weight (kg)
0.015
Lumens per Watt (lm/W)
144
Electric Class
1
Driver Integral?
Yes
Power Factor
0.97
Product Category
LED Luminaires - Not Plastic
Product Application
LED Batten
Outer Carton Barcode
1022400000004
Catalogue Page

Instructions

Photometric Data

Product Image
