Ultra Slim 1200mm

Ultra Slim 38W LED 4ft Single Batten - 4000K

Code
10270
Technical Specification
Volts (V)
220/240
The Ultra Slim LED Integrated Batten is a cost-effective shatterproof luminaire ideal for domestic applications. The Ultra Slim streamlined design gives the ability to seamlessly illuminate small spaces without the need for a large luminaire.
Download Specification
Full Specification
Downloads
Name
Ultra Slim 38W LED 4ft Single Batten - 4000K
Volts (V)
220/240
Candelas
1350
Life Hours
35000
Beam Angle
107°
CRI (Ra)
85
Guarantee
3 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
260mA
Energy Consumption (kWh/1000h)
38
IP Rating
IP20
Commodity Code
9405423100
EAN
5013588102702
Outer Box Qty
12
Height (mm)
26
Length (mm)
1230
Outer Box Height (mm)
1260
Outer Box Width (mm)
220
Outer Box Depth (mm)
190
Individual Product Weight (kg)
0.71
Outer Box Weight (kg)
10.68
Outer Box Volume
0.05267
Lumens per Watt (lm/W)
116
Depth (mm)
75
Wattage (W)
38
Equivalent Wattage (W)
75
Colour Temperature (K)
4000
Minimum Order Quantity
1
Single Box Weight (kg)
0.78
Single box Height (mm)
1235
Single box Width (mm)
85
Single Box Depth (mm)
33
Single Box Volume
0.00346
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Battens
EDATA Product Range
Ultraslim
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
4400
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
