Ultra Slim 1500mm

Ultra Slim 45W LED 5ft Single Batten - 4000K

Code
10271
Stock
Discontinued
This product has been discontinued. Please see our alternative listed below:
10271V2 - Ultra Slim V2 28/42W LED Integrated Power Selectable 5ft Batten - 4000K View product
Technical Specification
Volts (V)
220/240
The Ultra Slim LED Integrated Batten is a cost-effective shatterproof luminaire ideal for domestic applications. The Ultra Slim streamlined design gives the ability to seamlessly illuminate small spaces without the need for a large luminaire.
Quantity
Download Specification
Full Specification
Downloads
Name
Ultra Slim 45W LED 5ft Single Batten - 4000K
Volts (V)
220/240
Candelas
1650
Life Hours
35000
Beam Angle
118°
CRI (Ra)
85
Guarantee
3 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
400mA
Energy Consumption (kWh/1000h)
45
IP Rating
IP20
Commodity Code
9405423100
EAN
5013588102719
Outer Box Qty
12
Height (mm)
26
Length (mm)
1530
Outer Box Height (mm)
1560
Outer Box Width (mm)
220
Outer Box Depth (mm)
190
Individual Product Weight (kg)
0.91
Outer Box Weight (kg)
13.16
Outer Box Volume
0.06521
Lumens per Watt (lm/W)
118
Depth (mm)
75
Wattage (W)
45
Equivalent Wattage (W)
90
Colour Temperature (K)
4000
Minimum Order Quantity
1
Single Box Weight (kg)
1.02
Single box Height (mm)
1535
Single box Width (mm)
85
Single Box Depth (mm)
33
Single Box Volume
0.00431
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Battens
EDATA Product Range
Ultraslim
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
5300
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Catalogue Page
