Firestay CCT V2 Downlight

Firestay 5/7W LED CCT Dimmable Wattage Switchable Fixed Downlight

Code
08187V2
Stock
Discontinued
This product has been discontinued. Please see our alternative listed below:
10510V2 - Firestay 7/5W LED 4 CCT Downlight - Dim, 60° With White Bezel (Tool Free Lever Connector) View product
Technical Specification
Volts (V)
220/240
Our flagship downlight has received a major facelift for 2024! The Firestay CCT now includes a 4-way colour switch and 2-way wattage switch as standard. With an upgraded 10-year warranty, the new Firestay CCT is truly a fit and forget market leading downlight.
Quantity
Download Specification
Full Specification
Downloads
Name
Firestay 5/7W LED CCT Dimmable Wattage Switchable Fixed Downlight
Commodity Code
9405423990
EAN
5013588900001
Volts (V)
220/240
Life Hours
70000
Frequency (Hz)
50/60
IP Rating
IP65
Height (mm)
45
Diameter (mm)
82
Individual Product Weight (kg)
0.215
Inner Box Weight (kg)
3.18
Inner Box Height (mm)
455
Inner Box Width (mm)
210
Inner Box Depth (mm)
95
Outer Box Weight (kg)
6.42
Outer Box Height (mm)
465
Outer Box Width (mm)
220
Outer Box Depth (mm)
205
Inner Box Qty
10
Outer Box Qty
20
Outer Box Volume
0.02097
Inner Box Volume
0.00908
Beam Angle
60°
CRI (Ra)
85
Lumens per Watt (lm/W)
137-159
Switching Cycles
100000
Wattage (W)
5/7
Colour Temperature (K)
2700/3000/4000/6000
Candelas
550-720
IK Rating
IK07
Minimum Order Quantity
1
Single Box Weight (kg)
0.268
Single box Height (mm)
100
Single box Width (mm)
88
Single Box Depth (mm)
85
Single Box Volume
0.00075
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Downlights
EDATA Product Range
Firestay LED CCT
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
5W = 684 (2700K) / 712 (3000K) / 793 (4000K) / 746 (6000K) - 7W = 1048 (2700K) / 1115 (3000K) / 1010 (4000K) / 970 (6000K)
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Dimmable
Yes
Arial Backlit
No
Arial Backlit IP65
No
Arial Backlit Plus
No
Arial Multi Plus
No
Arial T-Pro Multi
No
Candle
No
Capsule
No
Decorative
No
Dura Batten
No
Dura V2 Batten
No
Filament
No
Firestay Integrated
No
Firestay Integrated CCT
No
Firestay Integrated CCT V2
Yes
Firestay Slim
No
Firestay with PIR
No
Fluorescent
No
Genesis Lamp
No
GLS
No
Globe
No
Halogen
No
Incandescent
No
Lumo Wallpack
No
Lumo 2 Wallpack
No
Luna GU10 Spike Light
No
Luna GU10 Wall Light
No
Mentor Batten
No
Mentor V2 Batten
No
Platinum
No
Retro Lantern
No
Round
No
Skyline Mini
No
Squirrel Cage
No
Spectrum Bulkhead
No
Spectrum Exit Blade
No
Spectrum Exit Sign
No
Spectrum High Power Bulkhead
No
Spectrum Twin Spot
No
Tubes
No
Ultra Batten
No
Ultra V2 Batten
No
Single Box Packaging Material
Paper or cardboard
Inner Box Packaging Material
Paper or cardboard
Outer Box Packaging Material
Paper or cardboard
Domestic External Lighting
No
Retrofit Solutions
No
Apex
No
Cityline
No
Alto Street Light
No
Apex Dura CCT
No
Apex Mentor
No
Apex Ultra CCT
No
Arial Linus
No
Skyline Virtus CCT
No
GU10
No
Spectrum Downlight
No
Muro Wallpack
No
Warranty
10 Years
Linears
No
Skyline Target
No
Catalogue Page

Instructions

Photometric Data

Product Image

Case Study Image
