Skyline Slim+ Standard

Skyline Slim+ 150W LED Floodlight - 4000K

Code
10991
Stock
Discontinued
This product has been discontinued. Please see our alternative listed below:
72036 - Skyline Omni 100/120/150W Wattage Switchable LED Floodlight - Symmetric - 3CCT View product
Technical Specification
Volts (V)
240
150W Skyline Slim LED Floodlight - IP65, 4000K
Quantity
Download Specification
Full Specification
Downloads
Name
Skyline Slim+ 150W LED Floodlight - 4000K
Volts (V)
240
Life Hours
50000
Beam Angle
110°
CRI (Ra)
80
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
1390mA
Energy Consumption (kWh/1000h)
150
IP Rating
IP65
Commodity Code
9405423990
EAN
5013588109916
Outer Box Qty
2
Height (mm)
357
Width (mm)
300
Depth (mm)
60
Outer Box Height (mm)
310
Outer Box Width (mm)
148
Outer Box Depth (mm)
367
Individual Product Weight (kg)
3.708
Outer Box Weight (kg)
8.21587
Outer Box Volume
0.01684
Lumens per Watt (lm/W)
135
Flex
1m
Windage
0.08m²
Power Factor
>0.9
Operating Temperature
-30°C to +35°C
Wattage (W)
150
Equivalent Wattage (W)
250
Colour Temperature (K)
4000
IK Rating
IK08
Minimum Order Quantity
1
Single Box Weight (kg)
3.92359
Single box Height (mm)
305
Single box Width (mm)
70
Single Box Depth (mm)
359
Single Box Volume
0.00766
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Floodlights
EDATA Product Range
Skyline Slim+
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
20188
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Arial Backlit
No
Arial Backlit IP65
No
Arial Backlit Plus
No
Arial Multi Plus
No
Arial T-Pro Multi
No
Candle
No
Capsule
No
Decorative
No
Dura Batten
No
Dura V2 Batten
No
Filament
No
Firestay Integrated
No
Firestay Integrated CCT
No
Firestay Integrated CCT V2
No
Firestay Slim
No
Firestay with PIR
No
Fluorescent
No
Genesis Lamp
No
GLS
No
Globe
No
Halogen
No
Incandescent
No
Lumo Wallpack
No
Lumo 2 Wallpack
No
Luna GU10 Spike Light
No
Luna GU10 Wall Light
No
Mentor Batten
No
Mentor V2 Batten
No
Platinum
No
Retro Lantern
No
Round
No
Skyline Mini
No
Squirrel Cage
No
Spectrum Bulkhead
No
Spectrum Exit Blade
No
Spectrum Exit Sign
No
Spectrum High Power Bulkhead
No
Spectrum Twin Spot
No
Tubes
No
Ultra Batten
No
Ultra V2 Batten
No
Single Box Packaging Material
Paper or cardboard
Inner Box Packaging Material
Paper or cardboard
Outer Box Packaging Material
Paper or cardboard
Domestic External Lighting
No
Retrofit Solutions
No
Apex
No
Cityline
No
Alto Street Light
No
Apex Dura CCT
No
Apex Mentor
No
Apex Ultra CCT
No
Arial Linus
No
Skyline Virtus CCT
No
GU10
No
Spectrum Downlight
No
Muro Wallpack
No
Warranty
5 Years
Linears
No
Skyline Target
No
Catalogue Page

Instructions

Photometric Data

Product Image

Case Study Image
