Arial Multi Emergency

Arial Multi Backlit LED 600x600 White Panel in Emergency (5Y) - 4000K

This product is made to order.
i
We have stock to build the quantity shown, but there is a 5-10 day lead time for delivery.
Code
11741
Technical Specification
Volts (V)
220/240
One of the newest panels in the Arial Multi range, comes with a 7 year warranty and 2 year on site warranty as standard. This cost-effective lighting solution is available with a multitude of optional extras.
Download Specification
Full Specification
Downloads
Name
Arial Multi Backlit LED 600x600 White Panel in Emergency (5Y) - 4000K
Volts (V)
220/240
Life Hours
50000
CRI (Ra)
85
Switching Cycles
25000
Frequency (Hz)
50/60
IP Rating
IP20
Height (mm)
595
Width (mm)
595
Depth (mm)
25
Commodity Code
9405423990
EAN
5013588117416
Individual Product Weight (kg)
1.715
Outer Box Qty
5
Lumens per Watt (lm/W)
138
Energy Consumption (kWh/1000h)
36
Unified Glare Rating
<22
Primary Material
Steel
Operating Temperature
0°C-35°C
Wattage (W)
20/26/30/36
Colour Temperature (K)
4000
TP(a)/TP(b)
TP(b)
Minimum Order Quantity
1
Single Box Weight (kg)
2.215
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Panels
EDATA Product Range
Arial Multi
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
20W = 3081 / 26W = 3845 / 30W = 4350 / 36W = 4961
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
Yes
Arial Backlit
No
Arial Backlit IP65
No
Arial Backlit Plus
No
Arial Multi Plus
No
Arial T-Pro Multi
No
Candle
No
Capsule
No
Decorative
No
Dura Batten
No
Dura V2 Batten
No
Filament
No
Firestay Integrated
No
Firestay Integrated CCT
No
Firestay Integrated CCT V2
No
Firestay Slim
No
Firestay with PIR
No
Fluorescent
No
Genesis Lamp
No
GLS
No
Globe
No
Halogen
No
Incandescent
No
Lumo Wallpack
No
Lumo 2 Wallpack
No
Luna GU10 Spike Light
No
Luna GU10 Wall Light
No
Mentor Batten
No
Mentor V2 Batten
No
Platinum
No
Retro Lantern
No
Round
No
Skyline Mini
No
Squirrel Cage
No
Spectrum Bulkhead
No
Spectrum Exit Blade
No
Spectrum Exit Sign
No
Spectrum High Power Bulkhead
No
Spectrum Twin Spot
No
Tubes
No
Ultra Batten
No
Ultra V2 Batten
No
Single box Height (mm)
670
Single box Width (mm)
627
Single Box Depth (mm)
36
Single Box Volume
0.01512
Outer Box Height (mm)
685
Outer Box Width (mm)
640
Outer Box Depth (mm)
250
Outer Box Volume
0.1096
Single Box Packaging Material
Paper or cardboard
Inner Box Packaging Material
Paper or cardboard
Outer Box Packaging Material
Paper or cardboard
Domestic External Lighting
No
Retrofit Solutions
No
Apex
No
Cityline
No
Alto Street Light
No
Apex Dura CCT
No
Apex Mentor
No
Apex Ultra CCT
No
Arial Linus
No
Skyline Virtus CCT
No
GU10
No
Spectrum Downlight
No
Muro Wallpack
No
Warranty
7 Years (5 Years Battery Warranty, 2 Years On Site)
