Aqua Endure Standard

Aqua Endure 18-36W LED CCT Power Switch Anti-Ligature Bulkhead + 7W Nightlight

Code
70039
Technical Specification
Volts (V)
220/240
The Aqua Endure is an anti-ligature and anti-vandal bulkhead, perfect for use in areas where a fitting's durability is paramount.
Download Specification
Full Specification
Downloads
Name
Aqua Endure 18-36W LED CCT Power Switch Anti-Ligature Bulkhead + 7W Nightlight
Volts (V)
220/240
Life Hours
100000
Beam Angle
117°
CRI (Ra)
80
Switching Cycles
50000
Frequency (Hz)
50/60
Energy Consumption (kWh/1000h)
36
IP Rating
IP66
Height (mm)
110
Diameter (mm)
400
Commodity Code
9405423990
EAN
5013588700397
Individual Product Weight (kg)
3.66
Outer Box Weight (kg)
10.82
Outer Box Height (mm)
470
Outer Box Width (mm)
470
Outer Box Depth (mm)
365
Outer Box Qty
2
Outer Box Volume
0.0806285
Lumens per Watt (lm/W)
158-173
Wattage (W)
18-36
Equivalent Wattage (W)
67
Colour Temperature (K)
3000/4000/6000
IK Rating
IK20
Minimum Order Quantity
1
Single Box Weight (kg)
4.83
Single box Height (mm)
165
Single box Width (mm)
447
Single Box Depth (mm)
447
Single Box Volume
0.032968485
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
LED Bulkheads
EDATA Product Range
Aqua Endure
EDATA Order Unit
Unit
EDATA Quantity Interval
1
UOM For Battery Weight
KG
Lumen output (lm)
18W = 2847 (3000K) / 3027 (4000K) / 3111 (6000K) - 23W = 3637 (3000K) / 3868 (4000K) / 3975 (6000K) - 28W = 4428 (3000K) / 4708 (4000K) / 4839 (6000K) - 36W = 5680 (3000K) / 6102 (4000K) / 6260 (6000K)
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Arial Backlit
No
Arial Backlit IP65
No
Arial Backlit Plus
No
Arial Multi Plus
No
Arial T-Pro Multi
No
Candle
No
Capsule
No
Decorative
No
Dura Batten
No
Dura V2 Batten
No
Filament
No
Firestay Integrated
No
Firestay Integrated CCT
No
Firestay Integrated CCT V2
No
Firestay Slim
No
Firestay with PIR
No
Fluorescent
No
Genesis Lamp
No
GLS
No
Globe
No
Halogen
No
Incandescent
No
Lumo Wallpack
No
Lumo 2 Wallpack
No
Luna GU10 Spike Light
No
Luna GU10 Wall Light
No
Mentor Batten
No
Mentor V2 Batten
No
Platinum
No
Retro Lantern
No
Round
No
Skyline Mini
No
Squirrel Cage
No
Spectrum Bulkhead
No
Spectrum Exit Blade
No
Spectrum Exit Sign
No
Spectrum High Power Bulkhead
No
Spectrum Twin Spot
No
Tubes
No
Ultra Batten
No
Ultra V2 Batten
No
Single Box Packaging Material
Paper or cardboard
Inner Box Packaging Material
Paper or cardboard
Outer Box Packaging Material
Paper or cardboard
Domestic External Lighting
No
Retrofit Solutions
No
Apex
No
Cityline
No
Alto Street Light
No
Apex Dura CCT
No
Apex Mentor
No
Apex Ultra CCT
No
Arial Linus
No
Skyline Virtus CCT
No
GU10
No
Spectrum Downlight
No
Muro Wallpack
No
Warranty
10 Years (2 Years On Site)
Linears
No
Skyline Target
No
Sports Halls
No
CFL/HID Alternative
No
Merit Batten
No
Catalogue Page

Instructions

Photometric Data

Product Image
