Nova

Nova LED DALI Retrofit T5/T8 Replacement - 4ft Single Pack

Code
60920
Technical Specification
Volts (V)
220/240
The Nova is a Magnetic T-Bar which attaches to an existing fitting, making it an ideal retrofit solution for replacing existing T5/T8 installations.
Download Specification
Full Specification
Downloads
Name
Nova LED DALI Retrofit T5/T8 Replacement - 4ft Single Pack
Volts (V)
220/240
Beam Angle
120°
CRI (Ra)
85
Frequency (Hz)
50/60
LED Drive Current
125-175mA
IP Rating
IP20
Height (mm)
28
Width (mm)
27
Length (mm)
1129
EAN
5013588609201
Commodity Code
9405423100
Individual Product Weight (kg)
0.43
Outer Box Weight (kg)
13.5
Outer Box Qty
20
Outer Box Height (mm)
238
Outer Box Width (mm)
420
Outer Box Depth (mm)
1158
Outer Box Volume
0.11575368
Lumens per Watt (lm/W)
150-160
Life Hours
50000
Guarantee
5 Years
Dimming Option
DALI
Operating Temperature
-30°C - +35°C
Wattage (W)
15/20
Equivalent Wattage (W)
38
Colour Temperature (K)
3000/4000
Candelas
578-823
IK Rating
IK06
Minimum Order Quantity
1
Single Box Weight (kg)
0.625
Single box Height (mm)
38
Single box Width (mm)
97
Single Box Depth (mm)
1146
Single Box Volume
0.004224156
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Order Unit
Unit
UOM For Battery Weight
KG
Lumen output (lm)
2250-3200
Dimmable
Yes
UOM For Packaging Dimensions
MM
UOM For Packaging Weights
KG
Made to Order
No
Arial Backlit
No
Arial Backlit IP65
No
Arial Backlit Plus
No
Arial Multi Plus
No
Arial T-Pro Multi
No
Candle
No
Capsule
No
Decorative
No
Dura Batten
No
Dura V2 Batten
No
Filament
No
Firestay Integrated
No
Firestay Integrated CCT
No
Firestay Integrated CCT V2
No
Firestay Slim
No
Firestay with PIR
No
Fluorescent
No
Genesis Lamp
No
GLS
No
Globe
No
Halogen
No
Incandescent
No
Lumo Wallpack
No
Lumo 2 Wallpack
No
Luna GU10 Spike Light
No
Luna GU10 Wall Light
No
Mentor Batten
No
Mentor V2 Batten
No
Platinum
No
Retro Lantern
No
Round
No
Skyline Mini
No
Squirrel Cage
No
Spectrum Bulkhead
No
Spectrum Exit Blade
No
Spectrum Exit Sign
No
Spectrum High Power Bulkhead
No
Spectrum Twin Spot
No
Tubes
No
Ultra Batten
No
Ultra V2 Batten
No
EDATA Product Family
LED Retrofit Solutions
EDATA Product Range
Nova
EDATA Quantity Interval
1
Single Box Packaging Material
Paper or cardboard
Inner Box Packaging Material
Paper or cardboard
Outer Box Packaging Material
Paper or cardboard
