Dura Double

Dura 40W LED Anti-Corrosive 4ft Double Batten in Emergency - 4000K

Code
06729
Technical Specification
Volts (V)
220/240
Watts (W)
40
Colour Temp (K)
4000
Lumens (lm)
6630
Energy Rating
E
The Dura LED Anti Corrosive Batten is one of BELL’s flagship Luminaires. This fully enclosed luminaire comes with stainless steel diffuser clips, ideal for exterior lighting projects that are open to the elements.
Download Specification
Full Specification
Downloads
Name
Dura 40W LED Anti-Corrosive 4ft Double Batten in Emergency - 4000K
Volts (V)
220/240
Watts (W)
40
Colour Temp (K)
4000
Lumens (lm)
6630
Life Hours
50000
Beam Angle
128°
CRI (Ra)
85
Guarantee
7 Years
Switching Cycles
25000
Frequency (Hz)
50/60
LED Drive Current
1080mA
Energy Consumption (kWh/1000h)
40
IP Rating
IP66
Commodity Code
9405409990
EAN
5013588067292
Country Of Origin
CN
UNSPSC Code
39111544
Individual Volume
0.01622
Outer Box Qty
6
Height (mm)
90
Width (mm)
125
Length (mm)
1263
Outer Box Height (mm)
215
Outer Box Width (mm)
310
Outer Box Depth (mm)
1290
Candelas (cd)
1600
Equivalent Watts (W)
90
Single Carton Height (mm)
95
Single Carton Width (mm)
135
Single Carton Depth (mm)
1265
Outer Box Volume
0.08598
Individual Product Weight (kg)
2.21
Single Carton Weight (KG)
2.46
Outer Box Weight (kg)
16.83
Plastic Packaging Weight (kg)
0.015
Impact Protection
IK10
Energy Rating
E
Lumens per Watt (lm/W)
166
Inner Box Qty
1
Electric Class
1
Power Factor
0.97kW
Driver Integral?
Yes
Emergency Lumen Output (lm)
414
