New ERP LED Halo MR16

Halo LED 4.9W MR16 - 38° Beam - 4000K

Code
60701
Next Delivery
28/02/2026 - 1,600 items
Technical Specification
Volts (V)
12
Cap
GU5.3
Energy Rating
F
The Halo MR16 provides a low voltage solution combined with sleek aesthetics. This lamp’s recently improved efficiency now means that it offers 100 lumens per watt as standard.
Download Specification
Full Specification
Downloads
Name
Halo LED 4.9W MR16 - 38° Beam - 4000K
Volts (V)
12
Cap
GU5.3
Life Hours
25000
Beam Angle
38°
Energy Rating
F
CRI (Ra)
85
Guarantee
3 Years
Switching Cycles
12500
Frequency (Hz)
50/60
LED Drive Current
450mA
Energy Consumption (kWh/1000h)
5
Height (mm)
45
Diameter (mm)
45
Commodity Code
8539520000
EAN
5013588607016
Inner Box Weight (kg)
0.358
Inner Box Height (mm)
260
Inner Box Width (mm)
110
Inner Box Depth (mm)
68
Outer Box Height (mm)
575
Outer Box Width (mm)
280
Outer Box Depth (mm)
155
Inner Box Qty
10
Outer Box Qty
100
Individual Product Weight (kg)
0.018
Outer Box Weight (kg)
4.06
Outer Box Volume
0.02496
Inner Box Volume
0.00194
Lumens per Watt (lm/W)
109
Wattage (W)
4.9
Colour Temperature (K)
4000
Candelas
650
Minimum Order Quantity
1
Single Box Weight (kg)
0.03
Single box Height (mm)
51
Single box Width (mm)
51
Single Box Depth (mm)
57
Single Box Volume
0.00015
EDATA Manufacturer ID Number
213673507
EDATA Manufacturer Name
BELL Lighting
EDATA Brand
BELL Lighting
EDATA Product Family
Lamps
EDATA Product Range
LED MR16
EDATA Order Unit
Unit
EDATA Quantity Interval
1
EPREL Product Type
LIGHT_SOURCE_VERSION
EPREL - Registered As
Importer
UOM For Battery Weight
KG
Mains or Non-Mains
Mains
Connected Light Source
No
Colour Tunable Light Source
No
High Luminance Light Source
No
Anti-Glare Shield
No
Lumen output (lm)
530
